Feeding Barge



       Through its own research and development, Haosail has provided many sets of feeding barges (platforms) for overseas breeding companies, and formed a series of our own barges. Haosail can supply various aquaculture barges (platforms) for all types of water and climate, including offshore, open sea, cold and tropical regions, depending on the volume of aquaculture. Our barges are designed and manufactured to withstand category 12 typhoons, providing users with a safe and reliable guarantee.

       The barges (platforms) are equipped with bait tanks, power fuel tanks, fish storage areas, control rooms, living areas, backup areas, and power equipment, feeding equipment, fish suction pumps, refrigeration equipment, monitoring sensing equipment, safety equipment and other optional equipment according to the needs of aquaculture. Other equipment and facilities can also be installed according to customer needs.

Model and Parameters


MODEL

LENGTH(m)

WIDTH(m)

DEPTH(m)

FULL LOAD DRAFT水(m)

FULL LOAD DISPLACEMENT(t)

BIN CAPACITY(t)

FUEL CAPACITY(m³)

LOAD CAPACITY(t)

WIND WAVE RESISTANCE GRADE

VOLUME OF SERVED NET CAGE (m³)

HS001-200型 20 7 2.6 1.8 350 25 15 250 12 ≥10000
HS002-500型 25 8 3 2 450 40 20 350 12 ≥20000
HS003-600型 30 10 3.7 2.4 600 60 25 500 12 ≥30000
CASE
